Table 83: Gigabit Ethernet uPIM RJ-45 Connector Pinout (continued)
FunctionSignal NamePin
Bidirectional pair +BBI_DB+3
Bidirectional pair +CBI_DC+4
Bidirectional pair -CBI_DC-5
Bidirectional pair -BBI_DB-6
Bidirectional pair +DBI_DD+7
Bidirectional pair -DBI_DD-8
Gigabit Ethernet ePIM RJ-45 Connector Pinout
Table 84 on page 234 describes connector pinout information for 1-port Gigabit
Ethernet ePIM ports.
Table 84: Gigabit Ethernet ePIM RJ-45
Connector Pinouts
SignalPin
MDI0+1
MDI0-2
MDI1+3
MDI2+4
MDI2-5
MDI1-6
MDI3+7
MDI3-8
Chassis Console Port Pinouts
The console port on a J-series Services Router chassis has an RJ-45 connector.
Table 85 on page 235 provides RJ-45 chassis console connector pinout information.
An RJ-45 cable is supplied with the router.
To connect the console port to an external management device, you need an RJ-45
to DB-9 serial port adapter, which is also supplied with the router.
234 ■ Gigabit Ethernet ePIM RJ-45 Connector Pinout
J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
