Table 5: Components of the Network Topology
SettingsProperty
•
ring-1—Data channel [200,300]
•
ring-2—Data channel [500,600]
Ring instances
Two customer sites are connected to AS 1:
•
Customer site 1, VLAN 200 and VLAN 300
•
Customer site 2, VLAN 500 and VLAN 600
Customer sites
CS1 has the following protection group properties:
•
RPL owner—ring-1.
•
East interface—ge-3/2/4.0.
•
West interface—ge-5/2/3.0.
•
Data channel for ring-1—VLAN 200, VLAN 300.
•
Data channel for ring-2—VLAN 500, VLAN 600.
•
Ring protection link end for ring-1—ge-3/2/4.0.
CS1 has the following routing and bridging properties:
•
Routing instance—vs.
•
Bridge domains:
•
bd100 is associated with vlan-id 100.
•
bd101 is associated with vlan-id 101.
•
bd200 is associated with vlan-id 200.
•
bd300 is associated with vlan-id 300.
•
bd500 is associated with vlan-id 500.
•
bd600 is associated with vlan-id 600.
CS1 router
CS2 has the following protection group properties:
•
RPL owner—ring-2.
•
East interface—ge-2/0/4.0.
•
West interface—ge-2/0/8.0.
•
Ring protection link end for ring-2—ge-2/0/8.0.
•
Data channel for ring-1—VLAN 200, VLAN 300.
•
Data channel for ring-2—VLAN 500, VLAN 600.
CS2 has the following bridging properties:
•
bd100 is associated with vlan-id 100.
•
bd101 is associated with vlan-id 101.
•
bd200 is associated with vlan-id 200.
•
bd300 is associated with vlan-id 300.
•
bd500 is associated with vlan-id 500.
•
bd600 is associated with vlan-id 600.
CS2 router
Copyright © 2012, Juniper Networks, Inc.156
