Figure 4: Destination NAT Single Address Translation
Table 10: Destination NAT Mapping
After TranslationBefore Translation
Translated Destination IP
Address
Source IP AddressDestination IP
Address
Source IP Address
192.168.2.21.1.1.31.1.1.320.20.20.20
In this topology, you provide access to the server (Server-HTTP-1) in the DMZ zone from
the Internet after translating the public IP address 1.1.1.3 to the private address 192.168.2.2
and forward traffic to the internal network if the request is coming from ge-0/0/0.0.
41Copyright © 2016, Juniper Networks, Inc.
Chapter 6: Configuring NAT for SRX Series
