Studio System Connection
Memo :
● For connections between the Camera Remote Control Units, refer to the [INSTRUCTIONS] of the Camera Remote Control
Unit.
* Models with an E suffix are for the European market and the UL Listing mark is not applicable.
CALLTALLY
INTERCOM
LEVEL
F3
MENU/SHUTTER GAIN
PAINT AUTO
BR
W.BAL
AUTO
MANU
WHITE MASTER BLACK
POWER
I
O
IRIS
STEP
SHUTTER
MENU
PUSH-ON
DOWN UP
VARIABLE
PUSH-ON
HIGH
LOW
B
A
PRESET
CLOSE OPEN
MID
DOWN UP
F4
REMOTE CONTROL UNIT RM-P250
FULL AUTO F1
SHUTTER
GAIN
F2
BARS
GY-HM790CHU/GY-HM790U/
GY-HM790CHE*/GY-HM790E*
Studio Viewfinder
VF-HP790G
Studio Adapter
KA-790G
Headset
(Beyerdynamic)
Multicore Remote Adapter
KA-M790G
26Pin Camera
Cable
VC-P110U (5m)
VC-P112U (20m)
VC-P113U (50m)
VC-P114U (100m)
Camera Remote Control Unit
RM-HP250AU/RM-HP250DE*
Remote Control
Unit RM-LP25U
Remote Control
Unit RM-LP25U
26Pin Camera Cable
VC-P110U (5m)
VC-P112U (20m)
VC-P113U (50m)
VC-P114U (100m)
Camera Remote Control Unit
RM-HP250AU/RM-HP250DE*
HD/SD-SDI
Component
26Pin Camera Cable
VC-P110U (5m)
VC-P112U (20m)
VC-P113U (50m)
VC-P114U (100m)
Camera Remote Control Unit
RM-HP250AU/RM-HP250DE*
Remote Control
Unit RM-LP25U
External Synchronizing
Signal
HD Switcher
GY-HM790CHU/GY-HM790U/
GY-HM790CHE*/GY-HM790E*
GY-HM790CHU/GY-HM790U/
GY-HM790CHE*/GY-HM790E*
Headset
(Beyerdynamic)
Headset
(Beyerdynamic)
Headset
(Beyerdynamic)
Headset
(Beyerdynamic)
Headset
(Beyerdynamic)
Studio Viewfinder
VF-HP790G
Studio Viewfinder
VF-HP790G
Studio Adapter
KA-790G
Studio Adapter
KA-790G
Multicore Remote Adapter
KA-M790G
Multicore Remote Adapter
KA-M790G
Coaxial cable (for E model)
Coaxial cable (for E model)
Coaxial cable (for E model)
