Basic System Diagram
CALLTALLY
INTERCOM
LEVEL
FULL AUTO F1
SHUTTER
GAIN
F2
F3
MENU/SHUTTER GAIN
PAINT AUTO
BR
W.BAL
AUTO
MANU
WHITE MASTER BLACK
POWER
I
O
IRIS
STEP
SHUTTER
MENU
PUSH-ON
DOWN UP
VARIABLE
PUSH-ON
HIGH
LOW
B
A
PRESET
CLOSE OPEN
MID
DOWN UP
F4
BARS
REMOTE CONTROL UNIT RM-P250
Shoulder Belt
Earphone
Focus Manual Unit
HZ-FM13 (FUJINON)
HZ-FM15 (CANON)
1/3 Zoom Lens
Th13x3.5BRMU(FUJINON)
Zoom Servo Control
HZ-ZS13B
1/2 Zoom Lens
Microphone
1/3 Zoom Lens
KT14x4.4KRSJ (CANON)
(GY-HM790U/GY-HM790E only)
Standard Package
Mount Converter
(1/2 B 1/3):ACM-12
Carrying Case
SDHC Memory Card
XLR 4P
AC Adapter
AC
Tripod
Composite Cable
BNC
Audio Cable
RCA pin
IEEE1394 Cable
4P-6P
Monitor
VTR
Non-linear Editing
System
BR-HD50U/E*
For GY-HM790CHE/GY-HM790E*
Anton Bauer
Battery
(Dionic90)
Remote Control Unit
RM-LP25U/RM-LP55U/
RM-LP57U
IDX
Battery Charger
External Recording
Device
Component Cable
BNC
Battery Adapter
Monitor
IDX Battery
(Endura)
Anton Bauer
Battery Charger
For GY-HM790CHU/GY-HM790U
SDI Cable
BNC
GY-HM790CHU/GY-HM790U : Gold Mount
GY-HM790CHE/GY-HM790E : V Mount
SDHC Card Reader
USB Cable
Mount Converter
(2/3 B1/3): ACM-17
2/3 Zoom Lens
Tripod Base
KA-551U
Non-linear Editing
System
PL Mount
Film Lens
16 mm PL Mount
Film Lens adapter
HZ-CA13U
Studio Adapter
KA-790G
Studio Viewfinder
VF-HP790G
Multicore Remote Adapter
KA-M790G
Memory Recorder
KA-MR100G
Headset
(Beyerdynamic)
Monitor
Remote Control Unit
RM-P210U/E*/RM-HP250AU/RM-HP250DE*
Remote Control Unit
RM-LP25U
(Connection is possible only
when RM-HP250AU/RM-
HP250DE* is used.)
