JVC KD-BT11 User Manual

ENGLISH
4 INTRODUCTIONS
Preparation
Cancel the display demonstration and set the clock
• See also page 20.
1
Turn on the power.
2
Enter the PSM settings.
3
Cancel the display demonstrations
Select “DEMO,” then “DEMO OFF.”
Set the clock
Select “CLOCK HOUR,” then adjust the hour.
Select “CLOCK MIN” (minute), then adjust the minute.
4
Finish the procedure.
When the power is turned off: Check the current clock time
When the power is turned on: Change the display information of the current source
FM/AM Frequency
= Clock = Station name *
1
= (back to the beginning)
CD/CD-CH Audio CD/CD Text: Current track number with the elapsed playing time
= Current track number
with the clock time = Disc title/performer *
2
= Track title *
2
= (back to the beginning)
MP3/WMA: Current track number with the elapsed playing time = Current track number with
the clock time = Album name/performer (folder name) *
3
= Track title (file name) *
3
= (back
to the beginning)
BLUETOOTH Current track number with the elapsed playing time
= Current track number with the clock time
= Album name/performer = Track title = (back to the beginning)
IPOD Folder name
= Track name = Current track number with the elapsed playing time = Current
track number with the clock time = (back to the beginning)
*
1
If no title is assigned to a station, “NO NAME” appears. To assign a title to a station, see page 23.
*
2
If the current disc is an audio CD, “NO NAME” appears.
*
3
If an MP3/WMA file does not have Tag information or “TAG DISPLAY” is set to “TAG OFF” (see page 21), folder name
and file name appear.
EN02-07_KD-BT11_001A_1.indd 4EN02-07_KD-BT11_001A_1.indd 4 10/31/07 5:41:03 PM10/31/07 5:41:03 PM

JVC KD-BT11 Specifications

General

MP3 playback	Yes
DVD Audio playback	No
FM band range	87.5 - 108 MHz
LW band range	144 - 279 kHz
Output power	50 W
Frequency range	16 - 20000 Hz
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	98 dB
File type	MP3/WMA

Weight and Dimensions

Dimensions (WxDxH)	182 x 52 x 159.5 mm
