5.1.6 DETAILS
Self check is performed for the following items:
5.1.7 METHOD OF DISPLAY WHEN A RASTER IS NOT OUTPUT
In the state where a raster is not output by breakdown of the set, an error is displayed by blink of the POWER LED.
< Explanation of operation >
If error is detected, the power is turned off. Shortly after the power is turned off, POWER LED will be blinked.
When the protection of low bias line short operates, the power cannot be turned on until the power cord takes out and inserts, after
the power is turned off.
Item OSD Content Condition to detect
LOB protect LOB LOB protect detected Start to detect 3sec after LOB is turned on.
Power off if it is being NG for 200ms.
Count is 0-9
EEPROM MEMORY MEN Total count of I
2
C error of EEPROM Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
Sound Meister MEI Total count of I
2
C error of Eala IC. Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
RF Tuner TUN Total count of I
2
C error of RF Tuner Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
HDMI HDM Total count of I
2
C error of HDMI Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
Synchronous SYN Whether there is Synchronous signal or not? It displays it to the input selecte signal.
The display is OK or NG.
Lamp using time TIME Display of panel drive time When LOB is turned It will be displayed in every
one hour. (Refer to Secton 1)
Clear motion drive CMD - Not used.
AV SW AV SW Total count of I
2
C error of AV SW Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
HDMI SW HDMI SW Total count of I
2
C error of HDMI SW Start to detect 3sec after LOB is turned on.
Count NG of acquisition I
2
C or NACK.
Count is 0-9
Type of error POWER LED flash cycle
Low bias line short protection Power LED turnig on and off at 1 second intervals.
