3-8(No.YA702<Rev.001>)
DIGITAL P.W. BOARD ASS'Y (SFU0D601A-H2)
 R9001 QRZ0107-474Z C RESISTOR 470k Ω 1/2W K
 R9005 QAD0141-4R0 N THERMISTOR 4 Ω
R9501 QRE121J-154Y C RESISTOR 150k Ω 1/2W J
R9502 QRZ0237-R18 UNF WW RESISTOR 0.18
Ω 3W J
R9503 QRT029J-R27 MF RESISTOR 0.27
Ω 2W J
R9504 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9505 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R9506 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9507 QRE121J-473Y C RESISTOR 47k
Ω 1/2W J
 R9508 QRZ9017-470 FUSI RESISTOR 47 Ω 1/4W J
R9509 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 R9510 QRZ9046-825Z C RESISTOR 8.2M Ω 1/2W K
R9511 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9512 QRL039J-220 OMF RESISTOR 22
Ω 3W J
R9513 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9514 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9517 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9518 NRSA63D-273X MG RESISTOR 27k
Ω 1/16W D
R9519 NRSA63D-152X MG RESISTOR 1.5k
Ω 1/16W D
R9520 NRSA63D-332X MG RESISTOR 3.3k
Ω 1/16W D
R9524 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R9525 NRSA63D-912X MG RESISTOR 9.1k
Ω 1/16W D
R9526 NRSA63D-821X MG RESISTOR 820
Ω 1/16W D
R9527 NRSA63D-822X MG RESISTOR 8.2k
Ω 1/16W D
R9551 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R9552 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R9553 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9555 QRL039J-121 OMF RESISTOR 120
Ω 3W J
R9604 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9605 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9606 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9607 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
L9503 QQLZ026-140 COIL 14uH
L9504 QQLZ026-140 COIL 14uH
L9701 QQR1827-001 CHOKE COIL
 T9501 QQS0444-001 SW TRANSF
 CP9501 ICP-N75-T IC PROTECTOR 2.7A
 CP9502 ICP-N75-T IC PROTECTOR 2.7A
 CP9506 QMFZ043-5R0Z-J1 FUSE 5A AC250V
 F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9505 QQR0621-002Z FERRITE BEADS
K9702 QQR1113-001Z FERRITE BEADS
K9703 QQR0621-002Z FERRITE BEADS
K9704 QQR0621-002Z FERRITE BEADS
K9705 QQR0621-002Z FERRITE BEADS
 LF9002 QQR1281-004 LINE FILTER
 LF9003 QQR1514-001 LINE FILTER
 PC9501 PS2581AL1/QW/ PHOTO COUPLER
 VA9001 QAF0060-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local
IC6001 R2A15112FP-X IC
IC6002 BH3547F-X IC
IC6003 MC4558CD-X IC
IC6661 NJU26123VC2-X IC
IC6771 AK4384ET-X IC
IC7001 R8J66619FP IC
IC7002 ATF64-32EX19A IC (SERVICE)
IC7003 25VF080B32EX19A IC(MICRO C ROM) (SERVICE)
IC7004 TC7WH08FU-X IC
IC7005 S-80928CLNB-G-W IC
IC9201 MM1689AH-X IC
IC9231 MM1663DH-X IC
IC9251 SI-8015Q-X IC
IC9401 SI-8005Q-X IC
IC9501 PQ090DNA1Z-X IC
IC9601 SI-8005Q-X IC
Q6104 2SC1623A/5-6/-X TRANSISTOR
Q6105 2SC1623A/5-6/-X TRANSISTOR
Q6501 2SA812A/5-6/-X TRANSISTOR
Q6503 2SC1623A/5-6/-X TRANSISTOR
Q7003 2SA812A/5-6/-X TRANSISTOR
Q7004 2SA812A/5-6/-X TRANSISTOR
Q7005 2SA812A/5-6/-X TRANSISTOR
Q7006 2SA812A/5-6/-X TRANSISTOR
Q7007 SSM3K02F-X MOS FET
Q7008 2SC1623A/5-6/-X TRANSISTOR
Q9702 2SC1623A/5-6/-X TRANSISTOR
 Ref No. Part No. Part Name Description Local
Q9703 2SC1623A/5-6/-X TRANSISTOR
Q9704 2SC1623A/5-6/-X TRANSISTOR
Q9705 2SC1623A/5-6/-X TRANSISTOR
D6301 RKZ5.1B2KG-X Z DIODE
D6501 HSU119-X SI DIODE
D6502 HSU119-X SI DIODE
D6503 HSU119-X SI DIODE
D6504 HSU119-X SI DIODE
D6505 HSU119-X SI DIODE
D7004 RKZ5.6B2KG-X Z DIODE
D7005 RKZ5.6B2KG-X Z DIODE
D7006 RKZ5.6B2KG-X Z DIODE
D7007 RKZ5.6B2KG-X Z DIODE
D7008 RKZ5.6B2KG-X Z DIODE
D7009 RKZ5.6B2KG-X Z DIODE
D7010 RKZ5.6B2KG-X Z DIODE
D7011 RKZ5.6B2KG-X Z DIODE
D7012 RKZ5.6B2KG-X Z DIODE
D7013 RKZ5.6B2KG-X Z DIODE
D7014 RKZ5.6B2KG-X Z DIODE
D7015 RKZ5.6B2KG-X Z DIODE
D7016 RKZ5.6B2KG-X Z DIODE
D7018 RKZ5.6B2KG-X Z DIODE
D7019 RKZ5.6B2KG-X Z DIODE
D9251 SJPB-L4-X SB DIODE
D9252 SJPB-L4-X SB DIODE
D9401 SJPB-L4-X SB DIODE
D9402 SJPB-L4-X SB DIODE
D9403 PTZ16B-X Z DIODE
D9404 HSU119-X SI DIODE
D9601 SJPB-L4-X SB DIODE
D9602 SJPB-L4-X SB DIODE
D9603 PTZ6.8B-X Z DIODE
D9604 HSU119-X SI DIODE
D9705 RKZ3.0B2KG-X Z DIODE
D9706 MA8024-X Z DIODE
C6101 NCB11AK-106X C CAPACITOR 10uF 10V K
C6102 NCB11AK-106X C CAPACITOR 10uF 10V K
C6105 NCB21AK-105X C CAPACITOR 1uF 10V K
C6106 NCB21AK-105X C CAPACITOR 1uF 10V K
C6107 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6109 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6111 NCB11AK-106X C CAPACITOR 10uF 10V K
C6112 NCB11AK-106X C CAPACITOR 10uF 10V K
C6113 NCB11AK-106X C CAPACITOR 10uF 10V K
C6114 NCB31AK-105X C CAPACITOR 1uF 10V K
C6116 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6117 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C6118 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6119 NCB11AK-106X C CAPACITOR 10uF 10V K
C6120 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6122 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C6123 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6124 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6125 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6126 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6301 NCJ21CK-106X-D C CAPACITOR 10uF 16V K
C6302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6303 NCJ21CK-106X-D C CAPACITOR 10uF 16V K
C6304 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
C6305 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C6306 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6307 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
C6308 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C6309 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6501 NEHL1CM-107X E CAPACITOR 100uF 16V M
C6504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6505 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6506 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6507 NEHL1CM-107X E CAPACITOR 100uF 16V M
C6508 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6509 NCB21AK-105X C CAPACITOR 1uF 10V K
C6510 NEHL0GM-227X E CAPACITOR 220uF 4V M
C6511 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6512 NEHL0GM-227X E CAPACITOR 220uF 4V M
C6513 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6514 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6515 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6516 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6518 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6520 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6662 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6663 NEHL1HM-475X E CAPACITOR 4.7uF 50V M
C6664 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6665 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6771 NEHL1CM-106X E CAPACITOR 10uF 16V M
C6772 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Ref No. Part No. Part Name Description Local
