3-12(No.YA702<Rev.001>)
PRINTED WIRING BOARD PARTS LIST [LT-32EX19/MAT]
ANALOG P.W. BOARD ASS'Y (SFU-1601A-H2)
REFER TO PARTS LIST IN PAGE 3-6 FOR THIS P.W. BOARD.
SW P.W. BOARD ASS'Y (SFU-7601A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
REMOTE P.W. BOARD ASS'Y (SFU-7602A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
LED P.W. BOARD ASS'Y (SFU-8601A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
POWER P.W. BOARD ASS'Y (SFU-9601A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
DIGITAL P.W. BOARD ASS'Y (SFU0D608A-H2)
 Ref No. Part No. Part Name Description Local
IC6001 R2A15112FP-X IC
IC6002 BH3547F-X IC
IC6003 MC4558CD-X IC
IC6661 NJU26123VC2-X IC
IC6771 AK4384ET-X IC
IC7001 R8J66619FP IC
IC7002 ATF64-32EX19M IC (SERVICE)
IC7003 25VF080B32EX19A IC(MICRO C ROM) (SERVICE)
IC7004 TC7WH08FU-X IC
IC7005 S-80928CLNB-G-W IC
IC9201 MM1689AH-X IC
IC9231 MM1663DH-X IC
IC9251 SI-8015Q-X IC
IC9401 SI-8005Q-X IC
IC9501 PQ090DNA1Z-X IC
IC9601 SI-8005Q-X IC
Q6104 2SC1623A/5-6/-X TRANSISTOR
Q6105 2SC1623A/5-6/-X TRANSISTOR
Q6501 2SA812A/5-6/-X TRANSISTOR
Q6503 2SC1623A/5-6/-X TRANSISTOR
Q7003 2SA812A/5-6/-X TRANSISTOR
Q7004 2SA812A/5-6/-X TRANSISTOR
Q7005 2SA812A/5-6/-X TRANSISTOR
Q7006 2SA812A/5-6/-X TRANSISTOR
Q7007 SSM3K02F-X MOS FET
Q7008 2SC1623A/5-6/-X TRANSISTOR
Q9702 2SC1623A/5-6/-X TRANSISTOR
Q9703 2SC1623A/5-6/-X TRANSISTOR
Q9704 2SC1623A/5-6/-X TRANSISTOR
Q9705 2SC1623A/5-6/-X TRANSISTOR
D6301 RKZ5.1B2KG-X Z DIODE
D6501 HSU119-X SI DIODE
D6502 HSU119-X SI DIODE
D6503 HSU119-X SI DIODE
D6504 HSU119-X SI DIODE
D6505 HSU119-X SI DIODE
D7004 RKZ5.6B2KG-X Z DIODE
D7005 RKZ5.6B2KG-X Z DIODE
D7006 RKZ5.6B2KG-X Z DIODE
D7007 RKZ5.6B2KG-X Z DIODE
D7008 RKZ5.6B2KG-X Z DIODE
D7009 RKZ5.6B2KG-X Z DIODE
D7010 RKZ5.6B2KG-X Z DIODE
D7011 RKZ5.6B2KG-X Z DIODE
D7012 RKZ5.6B2KG-X Z DIODE
D7013 RKZ5.6B2KG-X Z DIODE
D7014 RKZ5.6B2KG-X Z DIODE
D7015 RKZ5.6B2KG-X Z DIODE
D7016 RKZ5.6B2KG-X Z DIODE
D7018 RKZ5.6B2KG-X Z DIODE
D7019 RKZ5.6B2KG-X Z DIODE
D9251 SJPB-L4-X SB DIODE
D9252 SJPB-L4-X SB DIODE
D9401 SJPB-L4-X SB DIODE
D9402 SJPB-L4-X SB DIODE
D9403 PTZ16B-X Z DIODE
D9404 HSU119-X SI DIODE
D9601 SJPB-L4-X SB DIODE
D9602 SJPB-L4-X SB DIODE
D9603 PTZ6.8B-X Z DIODE
D9604 HSU119-X SI DIODE
D9705 RKZ3.0B2KG-X Z DIODE
D9706 MA8024-X Z DIODE
C6101 NCB11AK-106X C CAPACITOR 10uF 10V K
C6102 NCB11AK-106X C CAPACITOR 10uF 10V K
C6105 NCB21AK-105X C CAPACITOR 1uF 10V K
C6106 NCB21AK-105X C CAPACITOR 1uF 10V K
C6107 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6109 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6111 NCB11AK-106X C CAPACITOR 10uF 10V K
C6112 NCB11AK-106X C CAPACITOR 10uF 10V K
C6113 NCB11AK-106X C CAPACITOR 10uF 10V K
C6114 NCB31AK-105X C CAPACITOR 1uF 10V K
C6116 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6117 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C6118 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6119 NCB11AK-106X C CAPACITOR 10uF 10V K
C6120 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6122 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C6123 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6124 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6125 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6126 NEHQ1VM-227X E CAPACITOR 220uF 35V M
C6301 NCJ21CK-106X-D C CAPACITOR 10uF 16V K
C6302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6303 NCJ21CK-106X-D C CAPACITOR 10uF 16V K
C6304 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
C6305 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C6306 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6307 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
C6308 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C6309 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6501 NEHL1CM-107X E CAPACITOR 100uF 16V M
C6504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6505 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6506 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6507 NEHL1CM-107X E CAPACITOR 100uF 16V M
C6508 NCB21AK-475X C CAPACITOR 4.7uF 10V K
C6509 NCB21AK-105X C CAPACITOR 1uF 10V K
C6510 NEHL0GM-227X E CAPACITOR 220uF 4V M
C6511 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6512 NEHL0GM-227X E CAPACITOR 220uF 4V M
C6513 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6514 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6515 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6516 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6518 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6520 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6662 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6663 NEHL1HM-475X E CAPACITOR 4.7uF 50V M
C6664 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6665 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6771 NEHL1CM-106X E CAPACITOR 10uF 16V M
C6772 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6773 NEHL1CM-106X E CAPACITOR 10uF 16V M
C6774 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7002 NEHL0GM-227X E CAPACITOR 220uF 4V M
C7003 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7004 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7006 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7007 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7008 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7009 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7010 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NDC31HJ-220X C CAPACITOR 22pF 50V J
C7013 NDC31HJ-9R0X C CAPACITOR 9pF 50V J
C7014 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7015 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7017 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7018 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7019 NCB20JK-106X C CAPACITOR 10uF 6.3V K
C7020 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7021 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7022 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7023 NCB20JK-106X C CAPACITOR 10uF 6.3V K
C7024 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Ref No. Part No. Part Name Description Local
