!REF. PART No. PART NAME DESCRIPTION
R1119 NRSA63J-750X MG RESISTOR 75¯ 1/16W J
R1120 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1125 NRSA63J-750X MG RESISTOR 75¯ 1/16W J
R1126 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1131 NRSA63J-750X MG RESISTOR 75¯ 1/16W J
R1132 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1136 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1137 NRSA63J-101X MG RESISTOR 100¯ 1/16W J
R1138 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1139 NRSA63J-101X MG RESISTOR 100¯ 1/16W J
R1140 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1142 NRSA63J-103X MG RESISTOR 10k¯ 1/16W J
R1143 NRSA63J-103X MG RESISTOR 10k¯ 1/16W J
R1145 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1146 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1147 NRSA63J-333X MG RESISTOR 33k¯ 1/16W J
R1148 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1149 NRSA63J-333X MG RESISTOR 33k¯ 1/16W J
R1150 NRSA63J-750X MG RESISTOR 75¯ 1/16W J
R1151 NRSA63J-391X MG RESISTOR 390¯ 1/16W J
R1152 NRSA63J-391X MG RESISTOR 390¯ 1/16W J
R1153 NRSA63J-823X MG RESISTOR 82k¯ 1/16W J
R1154 NRSA63J-823X MG RESISTOR 82k¯ 1/16W J
R1156 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
R1157 NRSA63J-104X MG RESISTOR 100k¯ 1/16W J
R1160 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1161 NRSA63J-333X MG RESISTOR 33k¯ 1/16W J
R1162 NRSA63J-222X MG RESISTOR 2.2k¯ 1/16W J
R1163 NRSA63J-333X MG RESISTOR 33k¯ 1/16W J
R1202 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1205 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1208 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1211 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
R1213 NRSA63J-101X MG RESISTOR 100¯ 1/16W J
R1214 NRSA63J-101X MG RESISTOR 100¯ 1/16W J
R1215 NRSA63J-201X MG RESISTOR 200¯ 1/16W J
R1216 NRSA63J-201X MG RESISTOR 200¯ 1/16W J
R1218 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
L1001 QQL244K-4R7Z PEAKING COIL 4.7µH K
L1002 NQR0339-001X FERRITE BEADS
L1003 QQL244K-220Z P COIL 22µH K
L1004 QQL244K-180Z PEAKING COIL 18µH K
L1005 NQR0339-001X FERRITE BEADS
L1102 QQL244K-100Z PEAKING COIL 10µH K
L1202 NQL79GM-101X COIL 100µH M
L1203 NQL79GM-101X COIL 100µH M
L1204 NQL79GM-101X COIL 100µH M
CN1001 QGB1231M1-23 CONNECTOR B-B (1-23)
CN1002 QGB1231M1-23 CONNECTOR B-B (1-23)
J1001 QNN0725-004 PIN JACK VIDEO-1/OUT PUT
J1002 QNN0725-002 PIN JACK VIDEO-1/VIDEO-2
J1003 QNZ1012-001 D CONNECTOR PC IN
J1004 QNS0051-001 3.5 JACK DVI ANALOG AUDIO
J1005 QNN0833-001 PIN JACK PC AUDIO
K1101 NQR0389-003X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
TU1001 QAU0506-001 TUNER
SW P.W. BOARD ASS'Y
[7][1]
!REF. PART No. PART NAME DESCRIPTION
D7001 RKZ5.6B2KG-X Z DIODE
R7005 NRSA63J-101X MG RESISTOR 100¯ 1/16W J
R7101 NRSA63J-332X MG RESISTOR 3.3k¯ 1/16W J
R7102 NRSA63J-562X MG RESISTOR 5.6k¯ 1/16W J
R7103 NRSA63J-332X MG RESISTOR 3.3k¯ 1/16W J
R7104 NRSA63J-562X MG RESISTOR 5.6k¯ 1/16W J
R7105 NRSA63J-123X MG RESISTOR 12k¯ 1/16W J
R7106 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
L7001 NRSA02J-0R0X MG RESISTOR 0¯ 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0¯ 1/10W J
!REF. PART No. PART NAME DESCRIPTION
J7001 QNS0072-001 HEADPHONE JACK
K7001 NRSA63J-0R0X MG RESISTOR 0¯ 1/10W J
S7101 QSW1131-001Z TACT SWITCH VOL-
S7102 QSW1131-001Z TACT SWITCH VOL+
S7103 QSW1131-001Z TACT SWITCH TV/VIDEO
S7104 QSW1131-001Z TACT SWITCH POWER
S7105 QSW1131-001Z TACT SWITCH MENU/OK
S7106 QSW1131-001Z TACT SWITCH CH+
S7107 QSW1131-001Z TACT SWITCH CH-
REMOTE P.W. BOARD ASS'Y
[7][2]
!REF. PART No. PART NAME DESCRIPTION
IC7302 GP1UE281RKC1 IR DETECT UNIT
D7301 RKZ5.6B2KG-X Z DIODE
D7302 RKZ5.6B2KG-X Z DIODE
C7304 NCB11AK-106X C CAPACITOR 10µF 10V K
C7305 NCB11AK-106X C CAPACITOR 10µF 10V K
R7305 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
CN700G QJL001-072022-E SIN CR B-B WIRE
LED P.W. BOARD ASS'Y
[8][6]
!REF. PART No. PART NAME DESCRIPTION
Q8901 UN2212-X DIGI TRANSISTOR
Q8902 UN2110-X DIGI TRANSISTOR
D8901 SELT5E20CS/EF/T LED POWER
C8904 NCB31HK-103X C CAPACITOR 0.01µF 50V K
R8901 NRSA63J-103X MG RESISTOR 10k¯ 1/16W J
R8902 NRSA63J-151X MG RESISTOR 150¯ 1/16W J
R8912 NRSA63J-103X MG RESISTOR 10k¯ 1/16W J
POWER P.W. BOARD ASS'Y
[9][6]
!REF. PART No. PART NAME DESCRIPTION
IC9501 STR-Y6456-F3 IC
IC9503 SI-8001FFE-F3 IC
IC9515 TL431/A/-T IC
Q9501 2SC1627A/Y/-T TRANSISTOR
Q9551 RT1N241C-X DIGI TRANSISTOR
Q9552 RT1N241C-X DIGI TRANSISTOR
Q9601 2SC1623A/5-6/-X TRANSISTOR
Q9602 2SC1623A/5-6/-X TRANSISTOR
!D9001 D3SBA60 BRIDGE DIODE
D9501 RU3AM-LFC4 SI DIODE
D9504 MA8200/M/-X Z DIODE
D9505 MA8220/M/-X Z DIODE
D9506 SJPX-H6-W DIODE
D9511 1SS355W-X DIODE
D9512 1SS355W-X DIODE
D9520 FMX-G22S DIODE
D9521 FMX-G22S DIODE
D9522 FMX-G22S DIODE
D9523 MA8100/M/-X Z DIODE
D9601 RU3AM-LFC4 SI DIODE
