(No.YA702<Rev.001>)3-3
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST -1
P.W.B ASS'Y name
P.W.B ASS'Y No.
LT-32EX19/AT LT-32EX19/MAT LT-32EX19/PAT LT-32EX19/SAT
ANALOG P.W.B SFU-1601A-H2 ← SFU-1603A-H2 SFU-1601A-H2
SW P.W.B SFU-7601A-H2 ←←←
REMOTE P.W.B SFU-7602A-H2 ←←←
LED P.W.B SFU-8601A-H2 ←←←
POWER P.W.B SFU-9601A-H2 ←←←
DIGITAL P.W.B SFU0D601A-H2 SFU0D608A-H2 SFU0D609A-H2 SFU0D610A-H2
REMOTE CONTROL UNIT RM-C2020-1C ←←←
 Ref.No. Part No. Part Name Description Local
LV1 WJW0109-001A-E DIGITAL(LVDS)CABLE DIGITAL CN0LV-LCD PANEL UNIT
 1 GG10596-003A-H REAR COVER
 2 GG10562-002E-H FRONT PANEL
5 QAS0590-001 SPEAKER (x2)
 7 QMPRB50-170-Q1 POWER CORD 1.7m BLACK LT-32EX19AT,LT-32EX19MAT
 7 QMPRC70-165-Q1 POWER CORD 1.65m BLACK LT-32EX19PAT
 7 QMPN370-170-JC POWER CORD 1.7m BLACK LT-32EX19SAT
 8 GG20205-005A-H TERMINAL BASE
 9 GG10552-001D-H MAIN BASE
11 GG30180-001A-H BACK BRACKET (x2)
16 GG10591-001B-H STAND BASE UNIT
17 GG20215-001A-H SUPPORT PLATE
 20 LC34028-002A-H POWER CORD COVER
 21 GG30203-004A-H CONTROL ASSY
23 GG40042-001A-H CORD CLAMP
24 GG10589-001C-H TOP FRAME
33 GG30205-003A-H LCD SUPPORT BRACKET (x2)
38 GG10588-001B-H BOTTOM FRAME
50 QYSBSFG3014ZA TAP SCREW M3 x 14mm(x16)
51 QYSBSFG3014ZA TAP SCREW M3 x 14mm
52 QYSBSGG3008ZA TAP SCREW M3 x 8mm(x2)
53 QYSBSF3010ZA TAP SCREW M3 x 10mm(x3)
54 WJZ0354-001A-E WIRE DIGITAL-LED/REMOTE/SPEAKER
55 WJZ0316-001A-E WIRE POWER PWB-DIGITAL PWB
56 QZW0156-002 WIRE CLAMP (x3)
57 GG30206-001B-H EARTH PLATE (x5)
58 GG30206-002A-H EARTH PLATE (x8)
59 QYSBSFG3014ZA TAP SCREW M3 x 14mm
60 GG40076-001A-H SPACER SHEET
61 QQR0490-001 NOISE FILTER
62 WJZ0248-002A-E WIRE POWER PWB-LCD PANEL UNIT
63 QZW0028-001 WIRE CLAMP
64 GG30212-001B-H BRACKET SPACER
65 QYSSSP5008ZA SCREW M5 x 8mm(x4)
66 QYSPSPD5010MA SCREW M5 x 10mm(x4)
67 LC42759-001A-C FOOT (x6)
68 QQR0491-001 FERRITE CORE
69 GG40038-002A-H ABS SHEET (x9)
 200 SFU-9601A-H2 POWER PWB
 201 SFU-1601A-H2 ANALOG PWB
LT-32EX19AT,LT-32EX19MAT,LT-32EX19SAT
 201 SFU-1603A-H2 ANALOG PWB LT-32EX19PAT
 202 SFU0D601A-H2 DIGITAL PWB LT-32EX19AT
 202 SFU0D608A-H2 DIGITAL PWB LT-32EX19MAT
 202 SFU0D609A-H2 DIGITAL PWB LT-32EX19PAT
 202 SFU0D610A-H2 DIGITAL PWB LT-32EX19SAT
 203 SFU-7601A-H2 SW PWB
 204 SFU-8601A-H2 LED PWB
 208 SFU-7602A-H2 REMOTE PWB
