3-6(No.YA702<Rev.001>)
PRINTED WIRING BOARD PARTS LIST [LT-32EX19/AT]
ANALOG P.W. BOARD ASS'Y (SFU-1601A-H2)
 Ref No. Part No. Part Name Description Local
IC1001 R2A11018FP IC
IC1002 SN74LV04ANS-X IC
Q1001 2SA812A/5-6/-X TRANSISTOR
Q1002 2SC1623A/5-6/-X TRANSISTOR
Q1003 2SC1623A/5-6/-X TRANSISTOR
Q1004 2SC1623A/5-6/-X TRANSISTOR
Q1104 UN2226-X DIGI TRANSISTOR
Q1105 UN2226-X DIGI TRANSISTOR
Q1106 2SA812A/5-6/-X TRANSISTOR
D1103 RKZ5.6B2KG-X Z DIODE
D1106 RKZ5.6B2KG-X Z DIODE
D1109 RKZ5.6B2KG-X Z DIODE
D1112 RKZ5.6B2KG-X Z DIODE
D1113 RKZ10B2KG-X Z DIODE
D1114 RKZ10B2KG-X Z DIODE
D1117 RKZ5.6B2KG-X Z DIODE
D1118 RKZ10B2KG-X Z DIODE
D1119 RKZ10B2KG-X Z DIODE
D1122 RKZ5.6B2KG-X Z DIODE
D1125 RKZ5.6B2KG-X Z DIODE
D1130 RKZ5.6B2KG-X Z DIODE
D1133 RKZ10B2KG-X Z DIODE
D1134 RKZ10B2KG-X Z DIODE
D1135 RKZ10B2KG-X Z DIODE
D1137 RKZ10B2KG-X Z DIODE
D1138 RKZ5.6B2KG-X Z DIODE
D1139 RKZ5.6B2KG-X Z DIODE
D1140 RKZ10B2KG-X Z DIODE
D1141 RKZ10B2KG-X Z DIODE
C1001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1002 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1003 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1009 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1010 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1012 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1013 NCB31HK-821X C CAPACITOR 820pF 50V K
C1014 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1015 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1016 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1018 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1019 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1020 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1021 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1023 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1024 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1025 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1101 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1102 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1103 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1104 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1105 NCB31CK-105X C CAPACITOR 1uF 16V K
C1106 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1107 NCB31CK-105X C CAPACITOR 1uF 16V K
C1108 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1109 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1110 NCB31CK-105X C CAPACITOR 1uF 16V K
C1111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1112 NCB31CK-105X C CAPACITOR 1uF 16V K
C1113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1128 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1132 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1136 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1137 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1138 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1139 NCB31CK-105X C CAPACITOR 1uF 16V K
C1140 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1141 NCB31CK-105X C CAPACITOR 1uF 16V K
C1142 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1143 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1144 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1145 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1146 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1150 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1151 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1153 NCB31CK-105X C CAPACITOR 1uF 16V K
C1154 NCB31CK-105X C CAPACITOR 1uF 16V K
C1155 NCB31HK-391X C CAPACITOR 390pF 50V K
C1156 NCB31HK-391X C CAPACITOR 390pF 50V K
C1201 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1202 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1203 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1204 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1205 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1206 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1208 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1209 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1210 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1211 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1212 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1217 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1218 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1219 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1220 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1221 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1222 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1223 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1224 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C1225 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1226 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1227 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1228 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1229 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1230 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1231 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1232 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1233 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1234 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1237 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1238 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R1001 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1002 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1003 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1005 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1006 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1007 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1008 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1009 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1010 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R1011 NRSA63J-181X MG RESISTOR 180
Ω 1/16W J
R1012 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1013 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1014 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R1015 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R1016 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R1017 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1101 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1102 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1103 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1104 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1105 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1106 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1107 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1108 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1109 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1110 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1111 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1112 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1113 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1114 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1115 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1116 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1117 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1118 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1119 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1120 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1125 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1126 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1131 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1132 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1136 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1137 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1138 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1139 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1140 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1142 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1143 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1145 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1146 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1147 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1148 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1149 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1150 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1151 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
