2-32(No.YA702<Rev.001>)
ANALOG PWB
DIGITAL PWB(1/3)
TU1001-13
1.8 Vp-p
(H)
IC7001-114
2.1 Vp-p
(1µs)
IC7001-113
2.1 Vp-p
(1µs)
IC1001-28
0.3Vp-p
(H)
IC1001-18
0.1 Vp-p
(H)
IC7001-166
0.1 Vp-p
(H)
WAVEFORMS
