(No.YA702<Rev.001>)3-23
R6521 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6524 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R6663 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R6664 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R6665 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6666 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6667 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6668 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6669 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6670 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6672 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6673 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R6675 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6680 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6682 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6683 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6771 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6772 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6773 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6774 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6775 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6777 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6779 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R6780 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7002 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7004 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7005 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7006 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7007 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R7008 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7009 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R7010 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7011 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R7012 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7013 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7015 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7016 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7019 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7020 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7021 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7022 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R7023 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R7024 NRSA63D-392X MG RESISTOR 3.9k
Ω
1/16W D
R7025 NRSA63D-302X MG RESISTOR 3k
Ω
1/16W D
R7026 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R7027 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7028 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7029 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R7030 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7031 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R7032 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R7033 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7034 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7036 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7037 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7038 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7039 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7040 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7043 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7044 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7045 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7046 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7047 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R7048 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R7049 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R7050 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R7051 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7052 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7053 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R7054 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R7055 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7057 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7059 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7060 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7061 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7062 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7063 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7065 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R7066 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7067 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7069 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7071 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7073 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7074 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7075 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7076 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7077 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7078 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R7084 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7086 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7087 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7088 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7093 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7094 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7110 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7120 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R7121 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7122 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7123 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7126 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7128 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7129 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7130 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7131 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7133 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7134 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7135 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7136 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7137 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7138 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7139 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7142 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7143 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7144 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7145 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7146 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7147 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7148 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7149 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7150 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7151 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7152 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7153 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7154 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7155 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7156 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7157 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7158 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7159 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7161 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7163 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7164 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R7166 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7182 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7183 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7186 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7197 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7198 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7199 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9201 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9202 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9203 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9204 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9251 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9252 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R9253 NRSA63D-243X MG RESISTOR 24k
Ω
1/16W D
R9254 NRSA63D-822X MG RESISTOR 8.2k
Ω
1/16W D
R9255 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9256 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9401 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9402 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9403 NRSA63D-564X MG RESISTOR 560k
Ω
1/16W D
R9404 NRSA63D-154X MG RESISTOR 150k
Ω
1/16W D
R9405 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9406 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9407 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9408 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9409 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9410 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9501 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9502 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9601 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9602 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9603 NRSA63D-683X MG RESISTOR 68k
Ω
1/16W D
R9604 NRSA63D-154X MG RESISTOR 150k
Ω
1/16W D
R9605 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9606 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R9607 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9608 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9610 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9611 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9712 NRSA63D-223X MG RESISTOR 22k
Ω
1/16W D
R9713 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R9715 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9716 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R9717 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
RA7001 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
Ref No. Part No. Part Name Description Local
