Keba KeControl CP 507/C User Manual

CP 503/A, CP 505/A,D,K, CP 507/
A,C
Technical data
Project engineering manual V1.06
76
© KEBA 2021
Power output:
● KeBus 5 V:
Max. 10.5 W
1)
Max. 20 W (with additional output power)
2)
● KeBus 24 V: Max. 48 W
● Terminal X00B: Max. 72 W
● Extension bus 3.3 V: Max. 1.8 W
● Extension bus 24 V: Max. 4 W
1)
The total current or the output power of the 5 V KeBus and the USB inter-
face must not exceed 2.1 A or 10.5 W respectively.
2)
The current from the 5 V KeBus or the USB interface is 4 A or 900 mA re-
spectively. The output power of the 5 V KeBus or the USB interface is 20 W
or 4.5 W respectively.
CP 507/x
Nominal supply voltage:
24 V DC from the front (rated voltage toler-
ance 19.2 V DC to 30 V DC, in acc. with EN
61131-2)
Inrush current: Max. 10 A
Total power consumption: 174 W
Power output:
● KeBus 5 V: Max. 20 W
● KeBus 24 V: Max. 48 W
● Terminal X00B: Max. 72 W
● Extension bus 3.3 V: Max. 1.8 W
● Extension bus 24 V: Max. 4 W
12.4 Computer kernel
Processor:
● CP 503/x:
Intel Atom Processor E3815 Single Core
1.46 GHz
● CP 505/x:
Intel Atom Processor E3827 Dual Core 1.75
GHz
● CP 507/x:
Intel Atom Processor E3845 Quad Core 1.91
GHz
Memory:
● CP 503/x: 1 GB Single Channel
● CP 505/x, CP 507/A: 2 GB Dual Channel
● CP 507/C: 4 GB Dual Channel
Battery-buffered SRAM:
512 kB (for available memory for retain data
see system manual)
