Keebox W150NR User Guide

KEEBOX Wireless 11n Router
Schedule
The Router allows the user the ability to manage schedule rules for various wireless settings, filter
features, firewall features and virtual server settings.
Fields Description
Name Enter a name for the schedule.
Day(s) Click the radio button to choose the desired day(s), either All Week or Select Day(s).
If the latter is selected, use the checkboxes directly below to specify the individual
days.
All Day – 24 hrs Tick the check box to apply the new schedule rule to a full day.
Start Time If the schedule rule is not applied to a full day, specify the starting time of the schedule
rule in this field.
End Time If the schedule rule is not applied to a full day, specify the ending time of the schedule
rule in this field.
Click Add to save the changes and see the rule in the Schedule Rules List. To remove specific schedule
rules, tick the corresponding check boxes under Select, and click Delete Selected. To remove all entries,
click Delete All. Click Reset to clear all the information that has not been saved.
Click Apply to save the changes.
13

Keebox W150NR Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
Minimum system requirements	- Internet Explorer 6.0, Firefox, Safari, Chrome
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Routing protocols	RIP-1, RIP-2
Supported network protocols	PPPoE, PPTP, L2TP
Antennas quantity	1
Antenna gain level (max)	17 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Certification	- CE, FCC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	White
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	150 mm
Height	25 mm
Weight	200 g
