Kenwood DMX7017DABS User Manual

Basic Operations
15English
List screen
There are some common function keys in the
list screens of most sources.
61 2
3 4 5
1
Displays list type selection window.
2
Displays music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
•
: Plays all tracks in the folder containing
the current track.
•
: Jump to the letter you entered
(alphabet search).
•
: Moves to the upper hierarchy.
5
[ ] / [ ] / [ ] / [ ] Page scroll
You can change the page to display more items
by pressing [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to previous screen.
NOTE
• Buttons which cannot be activated from the list
screen are not displayed.

Kenwood DMX7017DABS Specifications

General

MP3 playback	Yes
CD-R playback	No
Audio formats supported	AAC, DSD, FLAC, MP3, OGG, WAV, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, HFP, PBAP, SSP
Line outputs (RCA)	3
USB ports quantity	1
DIN size	2 DIN
Output power	200 W
Product color	Black
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.95 \
Display resolution	800 x 480 pixels
Power requirements	14.4V
Key illumination color	Multi
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW
Preset stations quantity	20
Operating temperature (T-T)	-10 - 60 °C
Cables included	Audio (3.5mm), DC, USB

Weight and Dimensions

Weight	1700 g
Dimensions (WxDxH)	182 x 153 x 112 mm
