Remote control
71English
Remote control
This unit can be operated using the remote
control KNA-RCDV331 (optional accessory).
# CAUTION
Put the remote control in a place where it will
not move during braking or other operations.
A dangerous situation could result, if the
remote control falls down and gets wedged
under the pedals while driving.
Do not leave the battery near fire or under
direct sunlight. A fire, explosion or excessive
heat generation may result.
Do not recharge, short, break up or heat the
battery or place it in an open fire. Such actions
may cause the battery to leak fluid. If spilled
fluid comes in contact with your eyes or on
clothing, immediately rinse with water and
consult a physician.
Place the battery out of reach of children. In
the unlikely event that a child swallows the
battery, immediately consult a physician.
Battery Installation
If the remote control operates only over
shorter distances or does not operate at all, it
is possible that the batteries are depleted.
In such instances, replace the both batteries
with new ones.
1
Insert two AAA”/“R03”-size batteries
with the and poles aligned properly,
following the illustration inside the case.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kenwood DMX7017DABS and is the answer not in the manual?

Kenwood DMX7017DABS Specifications

General IconGeneral
MP3 playbackYes
CD-R playbackNo
Audio formats supportedAAC, DSD, FLAC, MP3, OGG, WAV, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedH.264, MKV, MPEG1, MPEG2, MPEG4, WMV
USB version2.0
Bluetooth version3.0+HS
Bluetooth profilesA2DP, HFP, PBAP, SSP
Line outputs (RCA)3
USB ports quantity1
DIN size2 DIN
Output power200 W
Product colorBlack
Audio output channels- channels
Equalizer bands quantity13
Maximum power per channel50 W
Display typeLCD
Display diagonal6.95 \
Display resolution800 x 480 pixels
Power requirements14.4V
Key illumination colorMulti
FM band range87.5 - 108 MHz
LW band range153 - 279 kHz
Supported radio bandsAM, FM, LW
Preset stations quantity20
Operating temperature (T-T)-10 - 60 °C
Cables includedAudio (3.5mm), DC, USB
Weight and Dimensions IconWeight and Dimensions
Weight1700 g
Dimensions (WxDxH)182 x 153 x 112 mm
