Kenwood DMX7017DABS User Manual

APPS—Android Auto™/Apple CarPlay/Mirroring
32
Spotify Operation
You can listen to the Spotify on this unit by
controlling the application installed in the
iPhone or Android.
To enter Spotify source, touch [Spotify] icon in
the source selection screen. (P.11)
Preparation
• Install the latest version of the Spotify application
"Spotify" on your iPhone or Android.
iPhone: Search for "Spotify" in the Apple App
Store to find and install the most current version.
Android: Search for "Spotify" in Google play to
find and install the most current version.
• iPhones are connected on either USB or
Bluetooth.
• Android devices are connected on Bluetooth.
• To connect a smartphone via Bluetooth, register
it as the Bluetooth device and do the App (SPP)
profile setting of the connection beforehand. See
Register from the Bluetooth unit (P.44) and
Connect the Bluetooth unit (P.46).
1
2
3
4
1
Artwork/ Playing time
• The picture data is displayed if available from
current content.
• For confirmation of play time.
2
Function bar
• [
] : Displays the Menu screen
• [
] : New radio station that relates to the
artist of the currently playing song is selected
and playback starts.
• [
] , [ ] : Skips the current song.
• [
] , [ ] : Plays or pauses the content of the
current station.
• [
] : Saves currently playing song to My
Music.
• [
] : Displays the Graphic Equalizer screen.
(P.66)
3
Content information
Displays the information of the current content
being played.
4
[ ] / [ ] / [ ] / [ ]
• [
] : Thumbs down to the current contents
and skip to the next contents.
• [
] : Registers the current contents as favorite
content.
• [
] : Repeats the current song.
• [
] : Randomly plays all song in current
playlist.
Ñ Selecting a track
1
Touch [ ].
 Menu screen appears.
2
Select the list type, then select a desired
item.
■ Selects the category and station
Touch the category and station name in the
list.
■ [
Top]
Returns to the first hierarchy of the list.
■ [
Up]
Returns to the previous list.

Kenwood DMX7017DABS Specifications

General

MP3 playback	Yes
CD-R playback	No
Audio formats supported	AAC, DSD, FLAC, MP3, OGG, WAV, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, HFP, PBAP, SSP
Line outputs (RCA)	3
USB ports quantity	1
DIN size	2 DIN
Output power	200 W
Product color	Black
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.95 \
Display resolution	800 x 480 pixels
Power requirements	14.4V
Key illumination color	Multi
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW
Preset stations quantity	20
Operating temperature (T-T)	-10 - 60 °C
Cables included	Audio (3.5mm), DC, USB

Weight and Dimensions

Weight	1700 g
Dimensions (WxDxH)	182 x 153 x 112 mm
