Bluetooth Control
45English
Step 3: Phonebook transfer
1
Select if you want to transfer your
phonebook data.
This message appears if the device
supports PBAP.
The phonebook data transmission starts.
Some smartphones may request
permission to access the data. The
data transmission will start with your
permission.
When the data transmission and
connection have completed, the Bluetooth
connection icon appears on the screen.
Bluetooth Setup
1
Press the [MENU] button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP Menu screen appears.
3
Touch [Bluetooth].
 Bluetooth SETUP screen appears.
See the following section for each
setting.
• Connect the Bluetooth unit (P.46)
• Change the PIN code (P.47)
• Change the device name (P.47)

Kenwood DMX7017DABS Specifications

General

MP3 playback	Yes
CD-R playback	No
Audio formats supported	AAC, DSD, FLAC, MP3, OGG, WAV, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, HFP, PBAP, SSP
Line outputs (RCA)	3
USB ports quantity	1
DIN size	2 DIN
Output power	200 W
Product color	Black
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.95 \
Display resolution	800 x 480 pixels
Power requirements	14.4V
Key illumination color	Multi
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW
Preset stations quantity	20
Operating temperature (T-T)	-10 - 60 °C
Cables included	Audio (3.5mm), DC, USB

Weight and Dimensions

Weight	1700 g
Dimensions (WxDxH)	182 x 153 x 112 mm
