Kenwood DPX502 User Manual

20
|
English
CD/USB device/Audio file/External disc control features
Function of non-iPod and non-"Music Editor" file
File Select 1 mode
Select the target folder by tracing the hierarchical
levels of folders. This is convenient when managing
audio files by folder.
1 Enter File Select 1 mode
Press the [F.SEL] button.
Select the "F-SEL1" display.
Folder name display
Displays the current folder name.
2 Select the folder
Operation type Operation
Movement between folders Push the Control knob towards right or left.
Selection of folder Push the Control knob towards up.
Return to previous folder Push the Control knob towards down.
Return to root folder Press the [3] button.
Select the folder containing the music you want to
listen to.
3 Determine the folder
Press the Control knob.
The music in the determined folder are displayed.
4 Select the music you want to listen to
Operation type Operation
Movement between music Push the Control knob towards right or left.
Return to folder selection
step
Press the Control knob for at least 1 second.
Return to root folder Press the [3] button.
5 Play the selected music
Press the Control knob.
Scrolling the file/folder name display
Push the Control knob toward up for at least 2
seconds.
Cancelling File Select 1
Press the [F.SEL] button twice.
Function of iPod, "Music Editor" file
File select
Selecting the music you want to listen to from the
device or media being played now.
1 Enter File Select mode
Press the [F.SEL] button.
Select the "F-SEL" display.
2 Search for a music
Select the category item using the Control
knob.
Operation type Operation
Movement between
items
Push the Control knob towards right or left.
Selection of item Press the Control knob.
Return to previous item Push the Control knob for at least 1 second.
Return to first item Press the [3] button.
Names of all the music are displayed in "SONGS" in
the audio file.
Selecting a music will play it from the beginning.
Cancelling File Select
Press the [F.SEL] button.
Function of Audio file
All Random Play
Playing randomly from all of the Audio files
recorded in the media.
Press the [A.RDM] button for at least 1 second.
When the random mode is ON, "ALL RDM" is
displayed.
Cancelling the All Random Play
Press the [A.RDM] button.
⁄
• When you push the Control knob toward [¢], the next
selected music starts.
• This function is not available on iPod and the music
edited by "Music Editor".
B64-3826-0000English.Indd20B64-3826-0000English.Indd20 07.4.2411:32:10AM07.4.2411:32:10AM

Kenwood DPX502 Specifications

FM Tuner Section

frequency range	87.9 MHz – 107.9 MHz
usable sensitivity	9.3 dBf (0.8 μV /75 Ω)
quieting sensitivity	15.2 dBf (1.6 μV /75 Ω)
frequency response	30 Hz – 15 kHz
signal to noise ratio (MONO)	70 dB
selectivity	≥ 80 dB
stereo separation	40 dB

AM Tuner Section

frequency range	530 kHz – 1700 kHz
usable sensitivity	28 dBμ (25 μV)

CD Player Section

spindle speed	1000 – 400 rpm (CLV 2times)
frequency response	10 Hz – 20 kHz
total harmonic distortion	0.008 %
signal to noise ratio	105 dB
dynamic range	93 dB

Audio Output

maximum output power	50 W x 4
full bandwidth power	22 W x 4
speaker impedance	4 - 8 Ω
preout level / load	2500 mV/10 kΩ
preout impedance	≤ 600 Ω

USB Interface

usb standard	USB 1.1/ 2.0
maximum supply current	500 mA

Auxiliary Input

frequency response	20 Hz – 20 kHz
input maximum voltage	1200 mV
input impedance	100 kΩ

General Specifications

operating voltage	14.4 V
current consumption	10 A
installation size (W x H x D)	182 x 112 x 160 mm
weight	3.53 lbs (1.60 kg)
