KNOW YOUR MITER SAW
Right Extension Wing
Hold-down Clamp
Right Bevel Detent Pin
Sliding Fence
Motor
Switch Handle
Carrying Handle
Laser Vertical
Adjustment Knob
Laser Horizontal
Adjustment Knob
Miter Lock Handle
Miter Angle Pointer
Laser Guide
Arbor Lock Button
Table Insert
Hand-hold for
Transportation
Bevel Scale
Mounting hole
Left Extension Wing
Lower Blade
Guard
Blade
Sliding Carriage
Hold-down Latch
Slide Carriage
Lock Knob
Table
Extension
Locking Lever
Positive Miter Stop
Bevel Lock Handle
