TP-6842 9/21 33
1.13.2 Auto Start Volt
This value is the voltage at which the 6VSG will automatically start. The automatic start criteria are met when this voltage has
reached or fallen below this value for the specified delay period (standard 3 minutes, only changed using SiteTech). This voltage
is detected at the generator and may differ from the voltage measured at the load or the battery due to voltage drop in the lines.
Figure 25 Auto Start Voltage Settings
1.13.3 Auto Stop Load
This value is the load level at which the 6VSG will automatically stop. The automatic stop criteria are met when the load has
reached or fallen below this value for the specified delay period (standard 3 minutes and only changed using SiteTech). This
load is detected at the generator.
Figure 26 Auto Stop Load Settings
1.13.4 Load Limit
This value is the limit to the generator capacity. This allows the 6VSG to limit current output to the maximum charge rate specified
by the battery manufacturer or load in the application. Adjustments should be done by qualified individuals after referring to
battery manufacturer’s recommended maximum charge rate.
Figure 27 Load Limit
Load Limit=
(Charge voltage x Charge current)
60
1.13.5 Delay (seconds)
This delay is used to determine the amount of time a value (Auto Start Volt or Auto Stop Load) needs to be sustained before the
respective action is taken pertaining to the value. The delay can only be changed using a personal computer (laptop) and Kohler
SiteTech software. Contact an authorized Kohler distributor or dealer to adjust the setting, if necessary.
Figure 28 Auto Start/Auto Stop Delay Settings
