49
EFI SYSTEM
62 690 05 Rev. E KohlerEngines.com
Code 0172
Component: Fuel System
Fault: Minimum adaptation limit exceeded
Condition: Too high pressure at high pressure fuel
line, TPS malfunction, shorted
connection, faulty sensor or fuel pump
module failure.
Conclusion: Oxygen Sensor Related
● Sensor connector or wiring.
● Sensor contaminated or damaged.
● Poor ground path.
● Pin circuit wiring or connectors.
ECU Black pin 10 or 17.
TPS Sensor Related
● Throttle plate position incorrect during
Learn procedure.
● TPS problem or malfunction.
Engine Wiring Harness Related
● Diff erence in voltage between sensed
voltage and actual sensor voltage.
● Problem in wiring harness.
● ECU-to-harness connection problem.
Systems Related
● Ignition (spark plug, plug wire, ignition
coil).
● Fuel (fuel type/quality, injector, fuel
pressure too high, fuel pump module or
lift pump).
● Combustion air (air cleaner dirty/
restricted).
● Base engine problem (rings, valves).
● Fuel in crankcase oil.
● Fuel pump module is over fi lled.
● Lift pump diaphragm is ruptured.
Code 0174
Component: Fuel System
Fault: Lean fuel condition
Condition: Fuel inlet screen/fi lter plugged, low
pressure at high pressure fuel line, TPS
malfunction, shorted connection or faulty
sensor.
Conclusion: TPS Learn Incorrect
● Lean condition (check oxygen sensor
signal with VOA and see Oxygen
Sensor).
Engine Wiring Harness Related
● Pin circuit wiring or connectors.
ECU pin Black 10, 12, 16 and 17.
Low Fuel Pressure
● Plugged fi lters.
● Bad lift pump.
Oxygen Sensor Related
● Sensor connector or wiring problem.
● Exhaust leak.
● Poor ground.
Poor system ground from ECU to engine,
causing rich running while indicating lean.
Fuel pump module connection. See Fuel
Components.
Code 0201
Component: Fuel Injector
Fault: Injector 1 Circuit Malfunction
Condition: Injector damaged or faulty, shorted or
open connection.
Conclusion: Injector Related
● Injector coil shorted or opened.
Engine Wiring Harness Related
● Broken or shorted wire in harness.
ECU pin Black 5.
● Wiring from Ignition.
ECU Related
● Circuit controlling injector #1 damaged.
To Next Page
