Kohler Command PRO EFI Series User Manual

Disassembly/Inspection and Service
9362 690 05 Rev. E KohlerEngines.com
Flywheel/Backing Shroud/Intake and Throttle Body/Air Cleaner Assembly Components
I
A
O
M
C
H
E
B
D
F
K
P
N
L
G
J
Q
R
S
T
E
D
G
H
I
J
K
L
N
M
O
P
A
Special Washer
(Style A)
B
Debris Screen
(Style A)
C
Stiff ener
(Style A)
D Flywheel Screw
E Washer F
Flywheel/Fan/Hex
Stud Assembly
(Style A)
G
Backing Shroud/
Intake Manifold/
Air Cleaner
H
Crankshaft Position
Sensor
I Stator J
Rectifi er-Regulator
Connector
K
MAP or TMAP
Sensor Connector
L Ground Lead
M Breather Hose N Oil Sentry
TM
O
Oil Temperature
Sensor
P Reducer Bushing
Q
Debris Screen
(Style B)
R
Support Ring
(Style B)
S
Spacer
(Style B)
T
Flywheel/Fan/Hex
Stud Assembly
(Style B)
Remove #2 Barrel and Valley Baffl es
1. Disconnect wiring harness lead from coil (#2 oil
cooler side).
2. Carefully depress back of high pressure fuel line
mounting clip and separate from #2 barrel baffl e.
Remove 5 screws (2 internal, 3 external), then
remove barrel baffl e (with coil installed).
3. Remove screws and #2 side valley baffl e.
4. If necessary, carefully depress clip & remove coil
from barrel baffl e.
