EFI SYSTEM
62 690 05 Rev. E KohlerEngines.com
Code 0351
Component: Ignition Coil
Fault: Cylinder 1 Ignition Coil Malfunction
Condition: Broken wire in harness (may not be
visible), shorted connection or faulty
sensor.
Conclusion: Engine Wiring Harness Related
● Connection to ignition or fuse.
● Pin circuit wiring or connectors.
● ECU pin Black 1.
● ECU-to-harness connection problem.
Ignition System Related
● Incorrect spark plug(s) used.
● Poor connection to spark plug.
Code 0352
Component: Ignition Coil
Fault: Cylinder 2 Ignition Coil Malfunction
Condition: Broken wire in harness (may not be
visible), shorted connection or faulty
sensor.
Conclusion: Engine Wiring Harness Related
● Connection to ignition or fuse.
● Pin circuit wiring or connectors.
ECU pin Grey 10.
● ECU-to-harness connection problem.
Ignition System Related
● Incorrect spark plug(s) used.
● Poor connection to spark plug.
Code 0562
Component: System Voltage
Fault: System Voltage Low
Condition: Faulty voltage regulator, bad fuse or
shorted connection.
Conclusion: Corroded Connections
Bad Stator
Bad Battery
● Low output charging system.
● Poor magnet in fl ywheel.
● Bad or missing fuse.
Code 0563
Component: System Voltage
Fault: System Voltage High
Condition: Faulty voltage regulator or shorted
connection.
Conclusion: Faulty Rectifi er-Regulator
Bad Stator.
Bad Battery.
Code 1693
Component: Tach Output (ECU)
Fault: Tach Circuit Low
Condition: Tachometer output circuit short to ground.
Conclusion: Bad Tach Wire (grounded).
GCU circuit short to ground.
Code 1694
Component: Tach Output (ECU)
Fault: Tach Circuit High
Condition: Tachometer output circuit short to battery.
Conclusion: ECU or GCU circuit error.
Code 61
Component: End of Code Transmission
Troubleshooting Flow Chart
Flow chart provides an alternative method of
troubleshooting EFI system. Chart will enable you to
review entire system in about 10-15 minutes. Using
chart, accompanying diagnostic aids (listed chart), and
any signaled fault codes, you should be able to quickly
locate any problems within system.
