TP-7091 4/23 55
5.7 Cold Weather Package
The cold weather package is recommended for reliable operation at temperatures below 0°C (32°F). The cold weather package
includes the kits shown in the following sections. The kits shown below are also available separately.
Hot engine and exhaust system.
Can cause severe injury or death.
Do not work on the generator set until it cools.
Servicing the engine heater. Hot parts can cause minor personal injury or property damage. Install the heater before
connecting it to power. Operating the heater before installation can cause burns and component damage. Disconnect power to
the heater and allow it to cool before servicing the heater or nearby parts.
5.7.1 Battery Heater
Optional 120 VAC and 240 VAC battery heater kits are available. The heater is thermostatically controlled. See Figure 47.
Wrap the heater around the battery and secure the cord using the strap or cable ties provided with the kit. See Figure 48. Plug
the power cord into an AC receptacle.
240 volt kits use a 3-pin power connector. Knockouts are located in the bulkhead for the 240 VAC power connector. The
240 volt battery heater kit includes an adapter harness that allows connection of up to three accessories.
Battery Heater Specifications
100-120 VAC or
200-240 VAC
50/60 Hz
Heater wrap rating, Watts
Battery wrap length, mm (in.)
Power cord length, mm (in.)
Figure 47 Battery Heater Specifications
Figure 48 Battery Heater, typical
Battery (not included
in battery heater kit)
Note:
Adapter harness for multiple accessories not shown.
Power cord for
240 volt kits
