Komatsu ecot3 GD655-5 User Manual

.
MAINTENANCE
WEAR PARTS
Blade 4.3m t19
Blade without side edges
but with end bits
232-70-12143
232-70-52190
(232-70-12450)
(232-70-12460)
(232-70-12480)
(01643-31645)
Edge
End bit
(Bolt)
(Bolt)
(Nut)
(Washer)
2
2
(32)
(4)
(36)
(36)
-
Blade
23B-70-31331
23B-735-3320
Guide bushing
Guide bushing
4
2
-
Circle
23B-70-31680
23B-70-51560
Wear plate
Guide
6
6
-
Scarifier 232-71-51320 Tooth 11 -
Ripper
234-785-1121
(113-78-21170)
Tooth
(Pin)
3
(3)
-
Front blade
233-971-5120
(232-70-12450)
(232-70-12480)
(01643-31645)
Edge
(Bolt)
(Nut)
(Washer)
2
(14)
(14)
(14)
-
4 - 9
