3-15
21. STANDARD TIGHTENING TORQUES FOR BOLTS AND NUTS
INSTALLATION OF GREASE PUMP (WA50 ONLY)
To install the grease pump to the holder on the floor surface, do
as follows.
When installing the tools to the machine also, install between the
holder, then fit the grease pump to the holder.
When doing this, be careful of the following.
1. Pull the grease pump chain to lock it.
(If the chain is not pulled, grease may ooze out.)
2. Fit a rubber band as shown in the diagram on the right to prevent
the grease pump lever from moving.
3. To prevent the grease pump chain from vibrating and making
noise, secure it with the pin as shown in the diagram on the right.
To Next Page
