13 SERVICE WORK ON THE CHASSIS 161
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking
effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
– Clean and oil the dust boots and inner fork tubes of both fork legs.
Universal oil spray ( p. 259)
– Press the dust boots back into their installation position.
– Remove excess oil.
K00854-10
(All TKC models)
–
Push dust boots
1
of both fork legs downward.
Info
The dust boots should remove dust and coarse dirt particles from the fork
tubes. Over time, dirt can accumulate behind the dust boots. If this dirt is
not removed, the oil seals behind can start to leak.
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking
effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
– Clean and oil the dust boots and inner fork tubes of both fork legs.
Universal oil spray ( p. 259)
– Press the dust boots back into their installation position.

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
