15 WHEELS, TIRES 187

K00540-11

– Operate the front brake and compress the fork a few times firmly.

The fork legs straighten.

–

Tighten screws

Guideline

Screw, fork stub M8 15 Nm

(11.1 lbf ft)

15.3 Removing the rear wheel

Preparatory work

– Raise the vehicle with the center stand. ( p. 138)

M00612-01

Main work

– Press the brake caliper by hand on to the brake disc in order to press back the brake

pistons.
