13 SERVICE WORK ON THE CHASSIS 168

13.27 Removing the crash bar

Preparatory work

– Raise the vehicle with the center stand. ( p. 138)

F00893-10

Main work

–

Remove fittings

F00894-10

–

Remove screws

and take off the clamp halves.

–

Remove screw

–

Remove screw

and take off right crash bar.
