23 TECHNICAL DATA 246

23.6 Tires

Validity Front tires Rear tires

(Super Adventure R EU) 90/90 V 21 M/C (54V) TL

Continental ContiTrailATTACK 2

150/70 ZR 18 M/C 70W TL

Continental ContiTrailATTACK 2

(All TKC models) 90/90 - 21 M/C 54T M+S TL

Continental TKC 80 Twinduro

150/70 B 18 M/C 70Q M+S TL

Continental TKC 80 Twinduro

The tires specified represent one of the possible series production tires. Additional information is available in the Service section under:

http://www.ktm.com

23.7 Fork

Fork article number 14.18.8Q.25

Fork WP Performance Systems 4860 ROTA SPLIT

Compression damping

Comfort 17 clicks

Standard 12 clicks

Sport 7 clicks

Full payload 7 clicks

Rebound damping

Comfort 17 clicks

Standard 12 clicks

Sport 7 clicks

Full payload 7 clicks

Spring preload - Preload Adjuster

Comfort 2 turns
