31 LIST OF SYMBOLS 264

31.3 Green and blue symbols

Green and blue symbols reflect information.

The left turn signal indicator lamp flashes green with a steady rhythmic flash – The left turn signal is switched on.

The high beam indicator lamp lights up blue – The high beam is switched on.

The idle indicator lamp lights up green – The transmission is in idle.

The cruise control system lamp lights up green – The cruise control system function is switched on and the speed

control is active.

The right turn signal indicator lamp flashes green with a steady rhythmic flash – The right turn signal is switched

on.
