KTM 1290 SUPER ADVENTURE R 2017 User Manual

15 WHEELS, TIRES 190
M00614-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the rear wheel bearing.
–
Clean and grease shaft seal ring
1
and contact surface
A
of the spacer.
Long-life grease ( p. 258)
– Insert the spacer.
– Clean and grease the thread of the wheel spindle and nut.
Long-life grease ( p. 258)
– Install the rubber dampers and rear sprocket carrier on the rear wheel.
– Place the rear wheel in the swingarm and bring the brake disc into contact with the
brake caliper.
M00615-10
–
Mount wheel spindle
2
but do not push it in all the way.
– Push the rear wheel forward as far as possible and lay the chain on the rear sprocket.

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
