16 ELECTRICAL SYSTEM 214

F00892-10

Main work

–

Turn adjusting wheel

to adjust the headlight range.

Info

Turn counterclockwise to increase the headlight range; turn clockwise to reduce

the headlight range.

If you have a payload, you may have to correct the headlight range.

400726-11

–

Set the headlight to marking

Guideline

The light-dark boundary must lie exactly on lower mark

when the motorcycle is

ready to operate with the rider mounted along with any luggage and a passenger if

applicable.
