KTM 1290 SUPER ADVENTURE R 2017 User Manual

22 TROUBLESHOOTING 237
Faults Possible cause Action
The ABS indicator lamp lights up ABS fuse is blown – Change the fuses in the fuse box. ( p. 210)
Wheel speeds of front and rear wheels
differ greatly
– Stop, switch off the ignition, start again.
Malfunction in ABS – Read out the fault memory using the KTM diag-
nostics tool.
High oil consumption Engine oil level too high – Check the engine oil level. ( p. 222)
Engine oil too thin (low viscosity) – Change the engine oil and oil filter and clean the
oil screens. ( p. 223)
The battery is discharged A power consumer is connected to the
socket/ACC1.
– Disconnect the power consumer from the
socket/ACC1.
– Recharge the battery. ( p. 203)
The hazard warning flasher is switched
on
– Switch off the hazard warning flasher.
– Recharge the battery. ( p. 203)
Battery is not charged by alternator – Check the charging voltage.
Ignition was not switched off when
vehicle was parked
– Recharge the battery. ( p. 203)

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
