KTM 1290 SUPER ADVENTURE R 2017 User Manual

23 TECHNICAL DATA 250
Screw, wind shield M5 3.5 Nm (2.58 lbf ft) –
Spoke nipple M5 5 Nm (3.7 lbf ft) –
Ground fitting on frame M6 6 Nm (4.4 lbf ft) –
Nut, ABS unit fixation M6 8 Nm (5.9 lbf ft) –
Remaining chassis nuts M6 10 Nm (7.4 lbf ft) –
Remaining chassis screws M6 10 Nm (7.4 lbf ft) –
Screw, angle sensor M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –
Screw, bushing M6 4 Nm (3 lbf ft) –
Screw, cable channel M6 5 Nm (3.7 lbf ft) –
Screw, chain guide M6 5 Nm (3.7 lbf ft) –
Screw, clutch assembly M6 5 Nm (3.7 lbf ft) –
Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –
Screw, cover part M6 6 Nm (4.4 lbf ft) –
Screw, engine guard M6 10 Nm (7.4 lbf ft) –
Screw, exhaust clamp M6 8 Nm (5.9 lbf ft) –
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, fuel pump M6 6 Nm (4.4 lbf ft) –
Screw, fuel tank M6 10 Nm (7.4 lbf ft) –
Screw, fuel tap M6 6 Nm (4.4 lbf ft) –
Screw, lower rear part M6 6 Nm (4.4 lbf ft) –
Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, retaining bracket, angle sensor M6 10 Nm (7.4 lbf ft) –

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
