KTM 1290 SUPER ADVENTURE R 2017 User Manual

23 TECHNICAL DATA 252
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) –
Nut, rear sprocket screw M10x1.25 50 Nm (36.9 lbf ft) Loctite
®
243™
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –
Screw, bottom shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased
Screw, top shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased
Nut, socket M18x1 4 Nm (3 lbf ft) –
Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased
Screw, steering head, top M22x1.5 18 Nm (13.3 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) Thread greased
Screw, front wheel spindle M25x1.5 45 Nm (33.2 lbf ft) Thread greased

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
