14 WHEELS, TIRES 113
14.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear wheel stand. ( p. 78)
– Raise the motorcycle with the front wheel stand. ( p. 79)
L02277-10
Main work
–
Remove screws
and push the fender to the side.
–
Remove screw
and pull wheel speed sensor
out of the hole.
–
Loosen screw
and screws
.
–
Unscrew screw
about 6 turns and press your hand on the screw to push the wheel
spindle out of the axle clamp. Remove screw
.
Warning
Danger of accidents Reduced braking effect caused by damaged brake discs.
– Always lay the wheel down in such a way that the brake discs are not dam-
aged.
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of the
fork.
Info
Do not pull the hand brake lever when the front wheel is removed.
