12
SERVICE
WORK
ON
THE
CHASSIS
89
12.13
Checking
the
chain,
rear
sprocket,
and
engine
sprocket
100132-10
–
Chec
k
the
rear
sprocket
and
engine
sprocket
for
wear.
»
If
the
rear
sprocket
and
engine
sprocke
t
are
worn:
–
Cha
nge
the
power
set.
Info
The
engine
sprocket,
rear
sprocket,
and
chain
should
always
be
replaced
together.
90
92
