7 COMBINATION INSTRUMENT 40
7.5 Indicator lamps
401686-01
Possible states
The turn signal indicator light flashes green simultaneously with the turn
signal – The turn signal is switched on.
The engine diagnosis warning lamp (MIL) lights up red – The OBD (on-
board diagnosis) has detected an emission- or safety-critical error.
The shift warning lights up/flashes red – The set shift speed has been
reached.
The idling speed indicator lamp lights up green – The transmission is
shifted to idle.
The high beam indicator lamp lights up blue – The high beam is switched
on.
The immobilizer indicator lamp lights up or flashes red – Status or error
message for immobilizer/alarm system. (OPTIONAL)
The general warning lamp lights up yellow – An operating safety (warning)
message was detected. This is also shown in the info display.
ABS warning lamp lights up/flashes yellow – Status or error messages relat-
ing to ABS (antilock brake system).
