7 COMBINATION INSTRUMENT 43

7.8 TRIP F display

401293-01

If the fuel level drops to the reserve mark, the display mode automatically changes to TRIP F

and starts to count from 0.0, regardless of the previous display mode.

Info

At the same time as the display mode TRIP F, the general warning lamp lights up

and the warning note Low Fuel Level appears on the info display.
