WIRING DIAGRAM 93
Components
A6 CDI controller
G2 Generator
L1 Pulse generator
L2 Ignition coil
X1 Plug-in connector, ignition curve
S9 Short circuit button
Cable colors
gn Green
gr-bl Gray-black
gr Gray
bl Black
ye-bl Yellow-black
bu-wh Blue-white
re Red
re-wh Red-white
re-bl Red-black
br Brown

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 250 SX 2010 and is the answer not in the manual?

KTM 250 SX 2010 Specifications

General IconGeneral
Displacement249 cc
Bore x Stroke66.4 mm x 72 mm
Cooling SystemLiquid-cooled
Transmission5-speed
Rear SuspensionWP Monoshock
Front BrakeSingle Disc, 260 mm
Rear BrakeSingle Disc, 220 mm
Seat Height992 mm
Ground Clearance385 mm
Fuel SystemCarburetor
IgnitionKokusan
StarterKickstarter
Front Tire80/100-21
Rear Tire110/90-19
Wheelbase1475 mm
Engine TypeSingle Cylinder, 2-Stroke
Front SuspensionWP USD Fork, 48 mm
Fuel Capacity7.5 liters
