TECHNICAL DATA 22
161
Screw, bottom triple clamp (All
standard EXC/XC-W models)
M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp (All
Six Days models)
M8 15 Nm (11.1 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, side stand attachment M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, subframe M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem (All stan-
dard EXC/XC-W models)
M8 20 Nm (14.8 lbf ft)
Screw, top steering stem (All
Six Days models)
M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
Screw, top triple clamp (All stan-
dard EXC/XC-W models)
M8 20 Nm (14.8 lbf ft)
Screw, top triple clamp (All
Six Days models)
M8 17 Nm (12.5 lbf ft)
Engine bracket screw M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Nut, fuel pump M12 15 Nm (11.1 lbf ft)
Screw, bottom shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Screw, top shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft)
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft)
Loctite
®
243™
