SERVICE WORK ON THE CHASSIS 11
81
Info
Clean up overflowed or spilled brake fluid immediately
with water.
11.44 Changing the hydraulic clutch fluid
Warning
Skin irritation Brake fluid causes skin irritation.
– Keep brake fluid out of the reach of children.
– Wear suitable protective clothing and safety glasses.
– Do not allow brake fluid to come into contact with the skin, the eyes or clothing.
– Consult a doctor immediately if brake fluid has been swallowed.
– Rinse the affected area with plenty of water in the event of contact with the skin.
– Rinse eyes thoroughly with water immediately and consult a doctor if brake fluid comes into contact
with the eyes.
– If brake fluid spills on to your clothing, change the clothing.
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with
the applicable regulations.
F00158-10
– Move the clutch fluid reservoir mounted on the handlebar to a
horizontal position.
–
Remove screws
1
.
–
Take off cover
2
with membrane
3
.
F01616-10
(All SX‑F models)
–
Fill bleeding syringe
4
with the appropriate hydraulic
fluid.
Syringe (50329050000)
Brake fluid DOT 4 / DOT 5.1 ( p. 138)
– On the clutch slave cylinder, remove the protection cap
and mount bleeding syringe
4
with appropriate hose
piece at the bleeder screw
5
.
–
Only loosen bleeder screw
5
on the clutch slave cylinder
to the point where filling is possible.
Info
Clean up overflowed or spilled brake fluid immedi-
ately with water.
Avoid contact between brake fluid and painted
parts. Brake fluid attacks paint.
Only use clean brake fluid from a sealed container.
