TECHNICAL DATA 22
141
22.4 Chassis
Frame Central tube frame made of chrome molybdenum steel
tubing
Fork (All SX‑F standard models, XC‑F US) WP Suspension Upside down AER 48
Fork (HERLINGS REPLICA) WP Suspension XACT 5548 AER 48
Fork (FACTORY EDITION) WP Suspension XACT 5548 AER 48
Suspension travel
front 310 mm (12.2 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber (All SX‑F standard models, XC‑F US) WP Suspension 5018 DCC Link
Shock absorber (HERLINGS REPLICA) WP Suspension XACT 5750 Link
Shock absorber (FACTORY EDITION) WP Suspension XACT 5750 Link
Brake system Disc brakes, floating brake calipers
Brake discs - diameter
front 260 mm (10.24 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 2.5 mm (0.098 in)
rear 3.5 mm (0.138 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary ratio 13:48
Chain 5/8 x 1/4"
Rear sprockets available 45, 47, 48, 49, 50, 51, 52
Steering head angle 63.9°
Wheelbase 1,485 ± 10 mm (58.46 ± 0.39 in)
Ground clearance, unloaded 370 mm (14.57 in)
Seat height, unloaded 950 mm (37.4 in)
Weight without fuel, approx. (SX‑F EU) 100 kg (220 lb.)
Weight without fuel, approx. (SX‑F US) 100.5 kg (221.6 lb.)
Weight without fuel, approx. (XC‑F US) 101 kg (223 lb.)
Weight without fuel, approx. (HERLINGS REPLICA) 101.2 kg (223.1 lb.)
Weight without fuel, approx. (FACTORY EDITION) 101.5 kg (223.8 lb.)
Maximum permissible front axle load 145 kg (320 lb.)
Maximum permissible rear axle load 190 kg (419 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
