22 TECHNICAL DATA
148
Weight of rider: 65 … 75 kg (143 … 165 lb.) 42 N/mm (240 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 45 N/mm (257 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 48 N/mm (274 lb/in)
Spring length 260 mm (10.24 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 105 mm (4.13 in)
Fitted length 477 mm (18.78 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 151)
22.9 Chassis tightening torques
Screw, air filter box cover EJOT PT
®
K60x20-Z 3 Nm (2.2 lbf ft)
Screw, combination switch EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, intake air temperature sen-
sor
EJOT DELTA PT
®
45x12‑Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Fitting, E-starter button M3 1 Nm (0.7 lbf ft)
Fitting, kill switch M3 1 Nm (0.7 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, service hour counter M4 1 Nm (0.7 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, frame protector M5 3 Nm (2.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Nut, cable on starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Fuel connection on fuel tank M8 15 Nm (11.1 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
