TECHNICAL DATA - ENGINE TIGHTENING TORQUES 184

Screw, engine housing M6x75 10 Nm (7.4 lbf ft) –

Screw, shift drum locating M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift lever M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, timing chain tensioning rail M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, starter engine M6 10 Nm (7.4 lbf ft) –

Screw, timing-chain tensioner M6 10 Nm (7.4 lbf ft) –

Plug, timing chain tensioner M8 10 Nm (7.4 lbf ft) –

Screw, cylinder head top section M6x30 10 Nm (7.4 lbf ft) –

Screw on cylinder head top section M6x45 10 Nm (7.4 lbf ft) –

Screw on cylinder head top section M6x50 10 Nm (7.4 lbf ft) –

Screw on cylinder head top section M6x55 – 10.9 10 Nm (7.4 lbf ft) –

Screw on cylinder head top section M6x75 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6 10 Nm (7.4 lbf ft) –

Screw, cylinder head M6 10 Nm (7.4 lbf ft) –

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Jet screw, oil line M8 10 Nm (7.4 lbf ft) –

Banjo bolt, oil line M8 10 Nm (7.4 lbf ft) –

Screw, generator cover M8 10 Nm (7.4 lbf ft) –

Plug, crankshaft location M8 10 Nm (7.4 lbf ft) –

Screw, camshaft gear M8 28 Nm (20.7 lbf ft)

Loctite

243™

Screw, engine sprocket M10 60 Nm (44.3 lbf ft)

Loctite

243™

Screw, cylinder head M10 Step 1

40 Nm (29.5 lbf ft)

Step 2

50 Nm (36.9 lbf ft)

–

KTM 450 XC User Manual
