KTM 690 Duke 2018 User Manual

BRAKE SYSTEM 13
113
Warning
Danger of accidents Driving aids can only prevent a
rollover within the physical limitations.
It is not always possible to compensate for extreme riding
situations, for example with luggage loaded with a high
center of gravity, varying road surfaces, steep descents or
full braking without disengaging the gear.
– Adapt your riding style to the road conditions and your
driving ability.
The ABS operates with two independent brake circuits (front and
rear brakes). During normal operation, the brake system operates
like a conventional brake system without ABS. When the ABS con-
trol unit detects a locking tendency in a wheel, ABS begins regu-
lating the brake pressure. The regulating process causes a slight
pulsing of the hand and foot brake levers.
The ABS indicator lamp
3
must light up after the ignition is
switched on and go out after starting off. If it does not go out after
starting off or if it lights up while riding, this indicates a fault in
the ABS system. In this case, the ABS is no longer enabled and
the wheels may lock during braking. The brake system itself stays
functional; only ABS control is not available.
The ABS indicator lamp may also light up if the rotating speeds of
the front and rear wheels differ greatly under extreme riding con-

KTM 690 Duke 2018 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	690 cc
Torque	74 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Transmission	6-speed
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Front Suspension	WP USD Ø 43 mm
Rear Suspension	WP Monoshock
Seat Height	835 mm
Dry Weight	148.5 kg
Fuel Capacity	14 liters
Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Power	73 hp (54 kW) @ 8, 000 rpm
Front Brake	Brembo four-piston radial caliper, 320 mm disc
Rear Brake	Brembo single-piston floating calliper, brake disc Ø 240 mm
ABS	Bosch 9M+ Two Channel ABS
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
